Product Overview
The PX-ZDY6500LPS(C) is a side-mounted tunnel drill rig developed for underground drilling programs in mining and tunneling operations. Its side-mounted configuration allows the rig to be installed directly against the tunnel wall, saving valuable floor space and improving accessibility in confined headings. The machine is engineered for borehole operations such as gas drainage, water exploration and water-inrush prevention, as well as other underground engineering duties. Built on the PX drilling platform, it combines stable feed control, dependable rotary drive and modular construction to support demanding drilling campaigns while keeping routine maintenance simple. It is a practical solution for mine operators seeking efficient, repeatable drilling in space-constrained underground environments.
Product Description
The design of the PX-ZDY6500LPS(C) places the drilling unit on a side-mounted frame so that operations can proceed close to the roadway wall without occupying the central travel path. This layout distinguishes it from conventional floor-mounted ZDY-series rigs and makes the machine well suited to narrow drifts, gate roads and other headings where space is at a premium. Rigid feed guides and a stable base support accurate borehole alignment, while the modular structure keeps transport, installation and relocation straightforward within the mine.
In operation, the rig supports gas drainage, water exploration and pressure-relief drilling across varied strata. The hydraulic feed and rotary systems work together to deliver controlled penetration and smooth rod handling during both drilling and retraction. Because final specifications are configured to project requirements, the PX-ZDY6500LPS(C) can be adapted to different borehole diameters, depths and site conditions without compromising underground safety or productivity.
Key Features
- Side-mounted installation that saves floor space and keeps the roadway clear
- Stable feed frame and guided mast for accurate borehole alignment
- Reliable hydraulic rotary drive with adjustable operating parameters
- Compact footprint that eases transport and repositioning underground
- Modular design for simplified maintenance and component replacement
- Compatible with a range of drill rods and bits for varied borehole programs
- Suited to gas drainage, water exploration and inrush-prevention drilling
- Safety-oriented controls and interlocks for underground operation
- Configurable according to project requirements and site conditions
Technical Specifications
| Parameter | Value |
|---|
| Equipment type | Side-mounted tunnel drill rig |
| Mounting mode | Side-mounted (against tunnel wall) |
| Drilling capacity | Subject to configuration |
| Rotary speed | Subject to configuration |
| Feed stroke | Subject to configuration |
| Hydraulic system | Subject to configuration |
| Installed power | Subject to configuration |
| Operating weight | Subject to configuration |
| Dimensions | Subject to configuration |
| Applications | Gas drainage, water exploration and inrush-prevention drilling |
Applications
The PX-ZDY6500LPS(C) is designed for underground tunnels and gate roads where floor space is limited, including coal and non-coal mines undertaking gas drainage, water exploration, inrush prevention or pressure-relief drilling. Its side-mounted layout reduces interference with transport and ventilation pathways, allowing drilling teams to work safely alongside other underground activities. Customers benefit from efficient borehole programs, lower installation effort and a machine that can be reconfigured to match evolving project demands.
![]()
