Side-mounted Tunnel Drill Rig PX-ZDY4600LPS(C)

Product Overview

The PX-ZDY4600LPS(C) is a side-mounted tunnel drill rig developed for heavier borehole programs in restricted underground workings. It is the lateral variant of the PX-ZDY4600LPS within the PX-ZDY series and supports drilling, water injection and pressure relief duties for coal mine gas control and tunneling projects. The side-mounted layout reduces the machine's width requirement while retaining the multi-purpose capability of the series. Several torque and depth classes are available, and the rig is configured by project requirements, with key values confirmed in the technical agreement and configuration sheet.

Product Description

The 4600LPS(C) is engineered for conditions where space is limited but drilling demands remain high. By shifting the drilling unit to the side of the chassis, the machine fits into drifts and roadways where a center-mounted layout would be difficult to deploy. The structure is built for stable operation across varied strata, and the arrangement preserves the control and reliability associated with the PX-ZDY high-capacity family.

Intended as a multi-purpose boring unit, the side-mounted rig handles drilling, water injection and pressure relief operations, supporting gas drainage and stress management programs in coal mines as well as larger underground borehole work. Torque, rotation, feed and auxiliary features are selected according to the client's project conditions rather than fixed by the base model designation. Final specifications therefore remain subject to configuration and are confirmed before delivery to ensure site compatibility.

Key Features

• Side-mounted drilling unit suited to restricted workings
• Lateral variant of the PX-ZDY4600LPS for heavier duties
• Supports drilling, water injection and pressure relief operations
• Reduced width requirement eases deployment in narrow drifts
• Multiple torque and depth classes available
• Configured by project requirements
• Final specifications confirmed through the technical agreement

Technical Specifications

Applications

The PX-ZDY4600LPS(C) suits gas drainage drilling, water injection and pressure relief in coal mines, as well as heavier borehole work in restricted tunneling and underground engineering sites. Its side-mounted arrangement allows higher-capacity drilling where space constraints prevent a standard layout, providing operators with a stable platform for demanding programs. Project-based configuration ensures the rig matches specific hole plans, strata conditions and site utilities before delivery.
