9 m Scaling Jumbo PX-XMPYT-9M | Large-section

Product Overview

The PX-XMPYT-9M is a 9-metre scaling jumbo developed for large-section underground roadways. Its maximum reach height of approximately 9,000 mm allows scaling and loose-rock handling across high headings that standard machines cannot safely cover. A full hydraulic pilot system delivers precise, controllable movement of the scaling boom, supporting careful roof and sidewall treatment. The machine is designed around the requirements of large-section roadway scaling construction, helping maintain stable openings and safe working conditions. Diesel or electric options are available by model, and final specifications are confirmed in the technical agreement and configuration sheet.

Product Description

The PX-XMPYT-9M extends the working envelope of the PX scaling jumbo range to approximately 9,000 mm of reach height, making it a practical choice for large-section roadways and high headings. The full hydraulic pilot system gives the operator accurate control over the scaling head, allowing loose rock to be brought down in a controlled sequence. Structural features are matched to large-section roadway work, where coverage height and stability are equally important.

The primary functions of the machine are scaling, loose-rock handling and safety maintenance, which together keep high openings stable and reduce rock-fall risk for crews working below. By covering more of the heading in a single setup, the unit supports efficient cycle times in underground development. The machine can be configured according to project requirements, and diesel or electric options are available by model depending on site conditions. Final specifications are defined in the technical agreement and configuration sheet.

Key Features

• Maximum reach height approx. 9,000 mm
• Designed for large-section roadways
• Full hydraulic pilot system
• Scaling, loose-rock handling and safety maintenance functions
• Low-profile underground design
• Diesel or electric options available by model
• Suited to underground scaling construction
• Configurable according to project requirements

Technical Specifications

Applications

The PX-XMPYT-9M is applied in large-section underground roadways, high headings and tunnel excavations where scaling reach beyond the range of standard machines is required. Loose-rock handling and safety maintenance performed at height help keep openings stable and protect personnel and equipment from rock-fall hazards. The machine supports efficient scaling coverage in wide or tall sections, contributing to safer and more continuous underground development. Power options such as diesel or electric can be selected according to site conditions, with final configuration confirmed in the technical agreement and configuration sheet.
