3D Transparent Mine System | Digital Mine Visualization

Product Overview

The 3D Transparent Mine System is built on a foundation of three-dimensional mine extraction engineering drawings, integrating safety monitoring, personnel positioning, roof pressure monitoring, video surveillance, and automation control systems. It achieves three-dimensional visualization, comprehensive integration, and alarm linkage for the mine — providing 3D visual support for safe production management.

Product Description

Traditional mine management relies on two-dimensional drawings, isolated monitoring dashboards, and text-based data displays — a fragmented approach that makes it difficult for managers to develop intuitive understanding of the spatial relationships between mine geometry, equipment, personnel, and hazards. The 3D Transparent Mine System transforms this paradigm by creating a comprehensive, interactive three-dimensional digital model of the entire mine — surface and underground — into which all operational data is integrated and visualized in its true spatial context.

The system's foundation is a 3D mine extraction engineering drawing that serves as the geometric base for full 3D simulation and modeling of all surface and underground scenes. Two-dimensional and three-dimensional data are unified, with 3D views automatically extending as new mining areas are developed. Users can navigate the model in two browsing modes: walking mode for detailed inspection of specific areas at human-perspective scale, and flying mode for rapid overview of large mine sections.

The comprehensive display system integrates production automation subsystem monitoring UIs and real-time equipment movement status display. The safety monitoring subsystem applies color-coding to gas anomaly zones and provides anomaly alarms and early warnings. Personnel and vehicle real-time positioning with historical trajectory replay allows managers to trace any individual's movement through the mine over any time period. The equipment management function displays equipment start/stop status, provides historical data queries, and computes equipment utilization rate statistics — enabling data-driven maintenance and capacity planning.

Video surveillance integration provides multi-IP, multi-channel information configuration management with PTZ control — bringing live camera feeds directly into the 3D model at their physical locations. Ventilation network simulation and solution modeling enables what-if analysis of ventilation system changes. Disaster simulation capabilities extend to water inrush, fire, and roof事故 simulations with escape route display — providing critical planning and training tools for emergency preparedness. The system's linkage alarm application uses the 3D graphics model as the spatial framework for alarm event visualization and response coordination, ensuring that all alarm information is presented in its true spatial context rather than as abstract text alerts.

Key Features

• Unified 2D/3D data with automatic 3D view extension
• Full 3D simulation of all surface and underground scenes
• Walking and flying browsing modes
• Integrated automation subsystem monitoring UI and equipment status display
• Safety monitoring: gas anomaly color-coding, alarm and early warning
• Personnel/vehicle real-time positioning and trajectory replay
• Equipment management: status display, history, utilization statistics
• Video surveillance integration with PTZ control
• Ventilation network simulation and disaster scenario modeling
• 3D graphics-based linkage alarm application

Technical Specifications

Applications

Coal mine 3D visualization, mine safety production management, emergency rescue command, and geological information query.
